3 Channel 5A DMX512 Decoder Controller Relay Switch Kit DIY Converter DMX Dimmer Relay With Protective Shell

Cliquez-ici pour vous assurer de la compatibilité de ce produit avec votre modèle
Comply with DMX512 international standard protocol
Built in change mode, you can adjust by dialing code

Added to wishlistRemoved from wishlist 0
Add to compare
Category:

Specifications


Working voltage: DC12V-24V
Relay load: 5A per channel
Controller: DMX512 3P D
mx512 Data: 0-127 Relay Switch OFF,128-255 Relay Switch ON
Size:120*55*20
Weight: 100g


DIP10 function key (FUN).


DIP10 (FUN) is OFF, as DMX512 mode, receive standard DMX512 signal. Occupies three address code, (R, G, B for each channel), DIP1-DIP9 address code setting.

When less than 127 DMX512 data relay off

DMX512 data is greater than 127 when the relay is closed

DIP10 (FUN) is ON, the built-in change mode and does not receive standard DMX512 signal. DIP1-DIP9 to invoke the built-in effects settings.

Cliquez-ici pour vous assurer de la compatibilité de ce produit avec votre modèle
Comply with DMX512 international standard protocol
Built in change mode, you can adjust by dialing code
DMX512 address code can be set via DIP
3 relay outputs,5A per channel

Specification: 3 Channel 5A DMX512 Decoder Controller Relay Switch Kit DIY Converter DMX Dimmer Relay With Protective Shell
