Audio Technica VM530EN/H Headshell/Dual Moving Magnet Cartridge Combo Kit with Elliptical Stylus 1’2″ Mount for 4-Pin Includes Mounting Hardware (Black/Orange)

AUDIO TECHNICA VM530EN/H Headshell/Cartridge Combo Kit Headshell/cart

The VM530EN/H combo kit includes the VM530EN elliptical nude dual moving magnet cartridge premounted on the AT-HS10BK universal 1/2″-mount headshell. The VM530EN is a top-end elliptical stylus cartridge in Audio-Technica’s new VM cartridge line – a line that harks back to A-T’s early days as a manufacturer primarily of high-end phono cartridges, while also incorporating today’s advanced technology. Like all VM cartridges, the VM530EN is equipped with dual magnets that are positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The cartridge’s lightweight 0.3 x 0.7 mil elliptical nude stylus reduces the execution mass of the vibration system, enabling fuller frequency reproduction and less tracking distortion than a bonded stylus. Includes mounting hardware.

Product Features

Frequency Response 20-25,000 Hz

Channel Separation 27 dB (1 kHz)

Vertical Tracking Force 1.8-2.2 g (2.0 g standard)

Stylus Construction Nude round shank

Recommended Load Impedance 47,000 ohms

Output 4.5 mV (at 1 kHz, 5 cm/sec)

Channel Balance 1.5 dB (1 kHz)

Stylus Shape 0.3 x 0.7 mil elliptical

Cantilever Aluminum pipe

Mount Half-inch

0

0

0

0

Cliquez-ici pour vous assurer de la compatibilité de ce produit avec votre modèle
Type VM Type Montage 1/2′ centres Réponse en Fréquence 20 – 25,000Hz Séparation des Canaux 27dB (1kHz) Equilibre des Canaux en Sortie 1.5dB (1kHz) Tension de Sortie 4.0mV (1kHz, 5cm/sec.) Angle de Piste Vertical 23? Force d’Appui Vertical 1.8 – 2.2g (2.0g standard) Type de Diamant Elliptical Nude Taille du Diamant 0.3 x 0.7 mil Fixation du Diamant Nude Round Shank Cantilever (levier porte-pointe) Aluminium
Pipe Impédance de la Bobine 2,700Ohm (1kHz) Compliance Statique 35 x 10-6 cm/dyne Compliance Dynamique 8 x 10-6 cm/dyne (100Hz) Impédance de Charge Recommandée 47,000Ohm Capacité de Charge Recommandée 100 – 200pF Poids 6.4g Dimensions 17.3 (H) x 17.0 (W) x 28.2 (L) mm Pointe de Lecture de Remplacement VMN30EN Accessoires Fournis Cartridge installation screws 5mm ×2 and 10mm ×2, Washer ×2, Hexagon nut ×2, Non-magnetic screwdr
iver ×1, Brush ×1, Lead wire set ×1
